INCA7011-02 Case
From
€5,117.00*
Gehäuse INCA7011-02
zur geschützen Aussenaufstellung
bestehend aus:
Kunststoffgehäuse, Stromversorgung, Controller, Display,
elektrisches Interface, Pumpen, Steuerventile, Heizung (optional)
Maße (B x H x T)
650 x 800 x 300 mm
Gewicht
40 kg
Schutzklasse
IP54
Stromversorgung
100–240 V, 50/60 Hz
Leistungsaufnahme
250 VA (mit Heizung max. 950 VA)
Gaseingänge
Messgaseingänge
2
Kalibriergaseingänge
1
Spülgaseingänge
1
Gasanschlüsse
Klemmringverschraubung 6 mm
max. Gaseingangsdruck
20 mbar rel.
min. Gaseingangsdruck
-100 mbar rel.
Rel. Gasfeuchte
< 95% kondensatfrei
Sicherheitseinrichtungen
Flammensperre Gaseingang
ATEX-Zulassung G IIC
interne Kondensatfalle
überwachter Gehäuselüfter
Gasförderung
langlebige Membranpumpe
interne Durchflussregulierung
Durchflussüberwachung
Umgebungsbedingungen
Betriebstemperatur
5–45 °C (mit Heizung -15–45 °C)
Feuchtigkeit
0–100 % relative Luftfeuchtigkeit
Umgebungsdruck
900–1250 hPa (0,9–1,2 bar)
Lagertemperatur
-20–60 °C
Schnittstellen
Relais
3 potentialfrei / frei konfigurierbar
optional bis zu 11
dig. Schnittstelle
RS232
Product number:
08200199793
Variants from €6,000.00*
INCA7011-05 Case
€7,500.00*
Housing INCA7011-05
for protected outdoor installation
consisting of:
plastic case, power supply, controller, display,
electrical interface, pumps, control valves, (heater option)
Dimensions (W x H x D)
650 x 800 x 300 mm
Weight
40 kg
Protection class
IP54
Power supply
100–240 V, 50/60 Hz
power consumption
250VA (with heater max. 950 VA)
Gas inlets
Sample gas inlets
5
Calibration gas inlets
1
Purge gas inlets
1
Gas connections
Compression fitting 6 mm
max. Inlet preassure
20 mbar gauge
min. Inlet preassure
-100 mbar gauge
rel. gas humidity
< 95% free of condensate
safety equipment
flame arrestor gas inlet
ATEX-certified G IIC
intrenal condensate trap
monitored case fan
Process gas extraction
long-life membrane pump
self-regulating process gas flow
internal flow monitoring
Ambient conditions
Operating temperature
5–45 °C (with heater -15–45 °C)
Humidity
0–100 % relative humidity
Barometric pressure
900–1250 hPa (0,9–1,2 bar)
Storage temperature
-20–60 °C
Interfaces
Relays
3 potential-free / freely configurable
(optional) up to 11
Communication interface
RS232
Product number:
08200199791
Isolation Tester type NR
€30,620.58*
Isolation Tester type NR
with fixed voltage
avilable voltages: 5kV, 10kV, 15kV, 20kV, 25kV, 30kV
fully electronic, including Ni-MH cells.
Accessories:
instruction manual
recharger cable
carrying strap
Product number:
04102199999
Isolation Tester type V
€30,000.00*
Isolation Tester type V
with adjustable voltage from 5 kV to 30 kV
fully electronic, including Ni-MH cells.
Accessories:
instruction manual
recharger cable
carrying strap
Product number:
04102199998
Manufacturer:
ABONA
